Section 6 · Pages 128–180 (53 pages)

Engine Mechanical

From the 1955 Pontiac Shop Manual

The 287 cu. in. Strato-Streak 90° V-8 with 8.0:1 or 7.4:1 compression, machined wedge combustion chambers, ball-pivot rocker arms and hydraulic lifters. It covers serial numbers, cleanliness rules, fan belt and lifter plunger adjustment, manifold, cylinder head, rocker stud, lifter, harmonic balancer, timing chain and camshaft replacement, engine removal and full overhaul of heads, valves, lifters, block, pistons, rods and camshaft bearings, and specifications.

Read this section free, starting at page 128

What this section covers

  • Engine description and serial numbers
  • Intake and exhaust manifolds
  • Cylinder head, valves and rocker arm studs
  • Hydraulic valve lifter service
  • Timing chain, camshaft and harmonic balancer
  • Connecting rods, pistons and main bearings
  • Engine removal, overhaul and installation
  • Specifications
Year
1955
Make
Pontiac
Vehicle
Passenger Cars
Type
Service Manual
Models
Star Chief (Series 28), Chieftain Eight Seventy 870 and Eight Sixty 860 (Series 27)
Publication
S-5504
Pages
400

What’s inside

Shop manual

  1. 00General Informationpp. 1–9
  2. 0General Lubricationpp. 10–17
  3. 1BodySerial number and body number plate locations and decoding, with notes on body shimming and adjustments; full body service is referred to the Fisher Body Service News.pp. 18–19
  4. 2FrameFrame checking chart with diagonal and point-to-point frame dimensions for Series 27 and 28 body styles, including Catalina and convertible.pp. 20–22
  5. 3Front Suspensionpp. 23–40
  6. 4Rear Suspension and Propeller Shaftpp. 41–75
  7. 5Brakespp. 76–89
  8. 5Power Brakes: Bendixpp. 90–105
  9. 5Power Brakes: Morainepp. 106–127
  10. 6Engine Mechanicalpp. 128–180
  11. 6AEngine Cooling and Lubricationpp. 181–190
  12. 6BEngine Fuel: Heat Control, Air Cleaner and Carter WGDpp. 191–210
  13. 6BEngine Fuel: Carter WCFB Four-Barrelpp. 211–228
  14. 6BEngine Fuel: Fuel and Vacuum Pumppp. 229–233
  15. 6BEngine Fuel: Rochester 2GCpp. 234–250
  16. 6BEngine Fuel: Rochester 4GCpp. 251–268
  17. 6CEngine Clutchpp. 269–275
  18. 7Transmission and Gearshift Controlpp. 276–296
  19. 9Steeringpp. 297–306
  20. 9Power Steering Gear and Pumppp. 307–327
  21. 10Wheels and Tirespp. 328–334
  22. 11Chassis Sheet MetalHood, fender, radiator support and bumper-grille adjustments, with removal of fenders, bumper and grille, hood hinges and springs, and battery support shimming.pp. 335–336
  23. 12Electrical and Instrumentspp. 337–385
  24. 14Accessoriespp. 386–393
  25. IndexAlphabetical subject index to the whole manual, listing topics by section page number (for example 6B-39 or 12-22).pp. 394–400
