Pages 38–43 (6 pages)

Steering

From the 1938 Chevrolet Passenger Car and Truck Service Information

The 1938 steering gear shared by Master and Master De Luxe, with built-in end stops, a roller sector on needle bearings on the Master and a 19 to 1 ratio, and a serrated steering wheel mounting. The adjustment procedure covers mast jacket alignment with shim 476612, worm bearing preload by spring scale, roller shaft end play, worm and roller backlash via the eccentric, and connecting rod ball joint adjustment.

Read this section free, starting at page 38

What this section covers

  • Roller sector and housing changes
  • Mast jacket alignment
  • Worm shaft end play and bearing load
  • Roller shaft end play
  • Worm and roller backlash adjustment
  • Steering connecting rod joints
Year
1938
Make
Chevrolet
Vehicle
Light Duty Trucks, Medium Duty Trucks, Passenger Cars, Trucks
Type
Service Manual
Models
Master and Master De Luxe passenger cars; 1/2-ton, 3/4-ton, 1-ton and 1-1/2-ton trucks and commercial models
Pages
75

What’s inside

Passenger cars

  1. Title Page and IntroductionCover, title page from Chevrolet Motor Division, and an introduction on why service men should learn the 1938 changes.pp. 1–3
  2. Enginepp. 4–8
  3. Coolingpp. 9–16
  4. Fuel Systempp. 17–20
  5. Clutchpp. 21–34
  6. TransmissionChanges to the carried-over Syncro-Mesh transmission: a redesigned clutch gear bearing nut and oil slinger, a bearing retainer that supports the throw-out bearing, and a stamped gearshift lever housing.pp. 35–35
  7. Rear AxleRear tread widened to 59 inches with a heavier housing and axle shafts, and new rear spring seats insulated by rubber bushings.pp. 36–37
  8. Steeringpp. 38–43
  9. BrakesHydraulic main cylinder improvements (check valve seat, primary cup insert, lock ring and boot) and the redesigned twelve-tooth hand brake lever.pp. 44–45
  10. Electricalpp. 46–63
  11. BodiesBody refinements for 1938: wider rear seat, new front seat back, draft-proof door sills, a larger Sport and Town sedan trunk with upright spare, Business Coupe deck lid spring, illuminated ignition lock and stronger front body brackets.pp. 64–66

Trucks

  1. Truckspp. 67–75
