Section 7 · Pages 230–258 (29 pages)

Three-Speed Transmissions and Overdrive

From the 1968 Chevrolet Series 10–60 Truck Chassis Overhaul Manual

Overhaul of the 3-speed manual transmissions: the fully synchronized Saginaw, the Muncie and the Warner units, each with disassembly, cleaning and inspection, subassembly repair and reassembly. The transmission overdrive follows, with removal of the overdrive housing from the adapter, disassembly, inspection and reassembly.

Read this section free, starting at page 230

What this section covers

  • 3-speed Saginaw transmission
  • 3-speed Muncie transmission
  • 3-speed Warner transmission
  • Transmission overdrive
Year
1968
Make
Chevrolet
Vehicle
Light Duty Trucks, Medium Duty Trucks, Trucks
Type
Overhaul & Unit Repair
Models
Series 10–60
Publication
ST-134-68
Pages
464

What’s inside

Overhaul manual

  1. 1Air Conditioning Compressorpp. 3–15
  2. 3Front Axle Differential (4-Wheel Drive)pp. 16–19
  3. 4Rear Axle Differential Carrierpp. 20–81
  4. 5Power Brake Cylinderspp. 82–127
  5. 6Enginepp. 128–161
  6. 6KWater Pumppp. 162–166
  7. 6MCarburetorspp. 167–201
  8. 6YStarting Motor, Solenoid and Delcotronpp. 202–223
  9. 7Clutchespp. 224–229
  10. 7Three-Speed Transmissions and Overdrivepp. 230–258
  11. 7Four-Speed Transmissionspp. 259–281
  12. 7Five-Speed Transmissionspp. 282–329
  13. 7Auxiliary Transmission and Transfer Casepp. 330–337
  14. 7Aluminum Powerglidepp. 338–356
  15. 7Turbo Hydra-Matic Transmissionpp. 357–409
  16. 9Steeringpp. 410–437

Specifications

  1. Specificationspp. 438–464
