Pages 223–240 (18 pages)

Specifications

From the 1972 Chevrolet Series 40–60 Truck Chassis Overhaul Supplement

Specifications for each section: rear axle torques, front brake data by truck model, Rochester carburetor specifications by model and engine, battery model application and Delcotron data, New Process 540 and 542 transmission torques and the mechanical steering gear application chart with adjustments and torques.

Read this section free, starting at page 223

What this section covers

  • Rear axle torques
  • Brakes
  • Rochester carburetor specifications
  • Battery application and engine electrical
  • Transmission torques
  • Steering gear application and adjustments
Year
1972
Make
Chevrolet
Vehicle
Medium Duty Trucks, Trucks
Type
Overhaul & Unit Repair, Supplement
Models
Series 40–60
Publication
ST-334-72
Pages
240

What’s inside

Overhaul supplement

  1. 4Rear Axle Differential Carrierpp. 3–48
  2. 5Brake Componentspp. 49–70
  3. 6MCarburetor: Holley 4150Gpp. 71–86
  4. 6YDelcotronpp. 87–96
  5. 7Clutches and Transmissionspp. 97–202
  6. 9Steeringpp. 203–222

Specifications

  1. Specificationspp. 223–240
