Section 10 · Pages 1091–1258 (168 pages)

Windshield, Instrument Panel, Doors and Hardware

From the 1940-1972 Buick Chassis and Body Illustration Catalog

Exterior mouldings and ornaments for each model from 1959 to 1972, windshield wipers and washers, instrument panel and floor consoles, front and rear door hardware by series, front door ventilators, weatherstrips, window and seat switches, vacuum door locks and the 1969–1972 rear view mirror and map lamp.

Read this section free, starting at page 1091

What this section covers

  • Exterior mouldings and ornaments
  • Windshield wiper and washer
  • Instrument panel and floor consoles
  • Front and rear door hardware
  • Door ventilators and weatherstrips
  • Vacuum door locks
Year
1940, 1941, 1942, 1943, 1944, 1945, 1946, 1947, 1948, 1949, 1950, 1951, 1952, 1953, 1954, 1955, 1956, 1957, 1958, 1959, 1960, 1961, 1962, 1963, 1964, 1965, 1966, 1967, 1968, 1969, 1970, 1971, 1972
Make
Buick
Vehicle
Buick Special and Skylark, Passenger Cars, Riviera
Type
Parts Catalog
Models
Special, Skylark, Gran Sport, Sportwagon, LeSabre, Invicta, Wildcat, Electra 225, Riviera; Century to Limited
Pages
1,678

What’s inside

Chassis illustrations

  1. Chassis General Information and Model Chartspp. 1–56
  2. 0Engine and Clutchpp. 57–92
  3. 1Engine Cooling and Oiling, Radiator Grillepp. 93–158
  4. 2Electricalpp. 159–258
  5. 3Fuel and Exhaust, Carburetionpp. 259–402
  6. 4Transmission and Brake Controlpp. 403–614
  7. 5Brake Operating, Propeller Shaft and Rear Axlepp. 615–662
  8. 6Front Suspension and Steeringpp. 663–724
  9. 7Frame, Shock Absorbers, Springs and Bumperspp. 725–788
  10. 8Sheet Metal, Heater Parts and Standard Partspp. 789–854
  11. 9Air Conditioning, Instrument Cluster and Heater Controlspp. 855–1040

Body illustrations

  1. Body Illustration Index, Trim and Paint Chartspp. 1041–1090
  2. 10Windshield, Instrument Panel, Doors and Hardwarepp. 1091–1258
  3. 11Rear Quarter Glass, Back Window and Seat Partspp. 1259–1278
  4. 12Body Mouldings and Body Sheet Metalpp. 1279–1530
  5. 13Wiring Harness and Folding Top Soft Trimpp. 1531–1538
  6. 14Folding Top Hardware, Cut Trim and Headliningspp. 1539–1560
  7. 15Rear Seat Trim, Rear Quarter Trim and Carpetpp. 1561–1678
