Carburation, Petrol Pump and Decarbonizing

From the 1934 SS Cars S.S. I and S.S. II Instruction Book

R.A.G. carburetters (Type T on the S.S. I, Type M on the S.S. II) and how to tune them by setting the idling speed regulator and fuel valve, followed by the AC petrol pump and its hand primer, fan belt adjustment, Trafficator bulb replacement and Lucas Alto and Altette horns. The decarbonizing and valve grinding procedure shows cylinder head nut sequences for both models, the valve spring compressor, ignition timing marks and refitting the distributor.

Read this section free, starting at page 20

What this section covers

  • R.A.G. carburetter tuning
  • AC petrol pump service
  • Lucas horns
  • Decarbonizing and valve grinding
  • Cylinder head nut sequence
  • Replacing the distributor
