Section 16-B · Pages 318–325 (8 pages)

Automatic Heating System

From the 1954 Cadillac Shop Manual

The Cadillac Deluxe Automatic Heating System with twin cowl heater units, two blowers and a dual thermostatic water valve, plus underseat heaters on the Series 75. It covers water flow, air flow and the electrical circuit, operation and adjustment of the Heat and Defr control levers, blower motor and heater unit removal, thermostatic control valve replacement, underseat heater service and a heater diagnosis chart.

Read this section free, starting at page 318

What this section covers

  • Water flow, air flow and electrical circuit
  • Heat and Defr control levers
  • Blower motor replacement
  • Heater unit removal and assembly
  • Thermostatic control valve
  • Series 75 underseat heaters
  • Heater diagnosis chart
