Section 6-A · Pages 37–40 (4 pages)

Headlining Assembly

From the 1961 Buick Body Service Manual

How the headlining is held by concealed listing wires, clips, retainers and a foundation board, and the step-by-step removal and installation. It lists the hardware and trim to remove first, notes which listing wire hole each wire must use, and gives cementing and tacking points at the windshield and back window. Tool J-2772 is used on retainer styles.

Read this section free, starting at page 37

What this section covers

  • Listing wires, clips and retainers
  • Hardware and trim to remove first
  • Removing the headlining
  • Installing listing wires in the correct holes
  • Cementing and tacking at windshield and back window
  • Headlining inserting tool J-2772
Year
1961
Make
Buick
Vehicle
Passenger Cars
Type
Body Service Manual
Models
LeSabre 4400, Invicta 4600, Electra 4700, Electra 225 4800
Pages
111

What’s inside

Body service manual

  1. 0Introduction and General Informationpp. 1–6
  2. 1-AWindshield Assemblypp. 7–12
  3. 1-BWindshield Wiper and Washer Assemblypp. 13–32
  4. 1-CInstrument PanelRemoval, installation and adjustment of the instrument panel compartment door, hinge stop, knob assembly and compartment, plus the end filler panel.pp. 33–34
  5. 1-DShroud Panel and Ventilating SystemHow the shroud air intake grille and side duct feed the body ventilating system, with removal and installation of the shroud top ventilator grille, side foundation, air outlet and outlet door, and duct sealing.pp. 35–36
  6. 6-AHeadlining Assemblypp. 37–40
  7. 7-AFolding Top General InformationGroup 7 section list and care of the convertible top: safety precautions, care of the plastic rear window, and cleaning the top with soap, water and mild foaming cleanser.pp. 41–42
  8. 7-BOperation of Folding Toppp. 43–46
  9. 7-CRoof Rail WeatherstripsRemoval, installation and adjustment of the front, center and rear side roof rail weatherstrips, and the front roof rail weatherstrips.pp. 47–48
  10. 7-DFolding Top AdjustmentsAdjusting misaligned folding top linkage: front roof rail corner brace, sunshade and striker support, hook lever, control link adjusting plate and male hinge support.pp. 49–51
  11. 7-EFolding Top Trim Assembly and Back Curtainpp. 52–62
  12. 7-FHydro-Lectric Systempp. 63–69
  13. 8-APower Window Circuits and Trouble Diagnosispp. 70–78
  14. 8-BPower Seat Circuits and Trouble Diagnosispp. 79–88
  15. 9-ABody Parts Lubricationpp. 89–93
  16. 10Exterior Moldings and Body Toolspp. 94–109
  17. Alphabetical IndexAlphabetical subject index to the full manual, with group-page references such as 0-2, 1-27, 7-23 and 8-10.pp. 110–111
